12-24V NT-CT1 Control Timer Relay

12-24V NT-CT1 Control Timer Relay.

SELECTABLE TIMING RANGES
– 1 to 255 seconds in 1 second increments
– 10 to 2550 seconds (42½ minutes) in 10 second increments
– 1 to 255 minutes (4 hours, 15 minutes) in 1 minute increments
– 1 to 255 hours (10 days, 15 hours) in 1 hour increments

14 OPERATING MODES
– Single shot
– Single shot retriggerable
– Single shot cancellable
– Dual edge triggered single shot
– Dual edge triggered single shot retriggerable.
– Bistable (clutch / toggle) operation
– Trigger Extension
– Maximum Pulse
– Minimum Pulse (retriggerable)
– Hold off (Door open too long)
– Multivibrator (strobe) with 1 second on time, selectable off time
– Multivibrator (strobe) with equal on/off times
– Delay on
– Delay on retriggerable (no activity timer)

• Accurate DIP switch selection (no pots)
• Selectable Positive, Negative or Dual Edge trigger
• Selectable Normally Open or Normally Closed trigger input
• Heavy duty 5 Amp change over relay
• LED indication of relay operation
