Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] – SIDE MOUNT OR BOTTOM MOUNT

Name: Global Access
SKU: f1641e223665g904
Rating: 4.6 (38 reviews)

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] - SIDE MOUNT OR BOTTOM MOUNT

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] - SIDE MOUNT OR BOTTOM MOUNT - Image 2

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] - SIDE MOUNT OR BOTTOM MOUNT - Image 3

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] - SIDE MOUNT OR BOTTOM MOUNT - Image 4

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] - SIDE MOUNT OR BOTTOM MOUNT - Image 5

Telescopic Cable + Pulley Driven Sliding Gate Kits [Suit Max. 6.3m Opening] – SIDE MOUNT OR BOTTOM MOUNT

SKU: 1539-0002#

product variations

Clear

Add to Quote

Related Files:

Share This Items :

Telescopic Cable + Pulley Driven Sliding Gate Kits – SIDE MOUNT OR BOTTOM MOUNT

• Quality Italian Made Hardware Components
• No need to adhere to a flat-top design as required in some other kits
• Just 58mm between the gate panels
• Suit Max. 6.3m opening

Bottom Mount Notes:
• 75mm W Box Section or wider is optimal, 65mm W Section can be used but is not recommended, 50mm W CANNOT be used
• MUST use Hi-Motions 120mmØ Wheels
• If using side covers and Box-Section used is under 90mm, trimming (notching) of the covers is required

Optional:
• Bottom / Side Mount Covers
