12V / 24V LED Flashing Light – Suitable for use during the Daytime

12V / 24V 11 Flash Pattern LED Flashing Light – Suitable for use during the Daytime

• Multi-voltage 12-24V (3.2A @12V)
• 18 x 3W LED (Suitable for daytime use)
• SAE J845, class 1 rated output
• 11 x flash patterns
• Polycarbonate lens for increased durability
• Die-cast aluminium base
• Operating Temp: -30°C to 50°C
• IP67

CAPABLE FLASH PATTERNS:
1 – Quad Burst
2 – Quad Flash
3 – Double Flash
4 – Single Flash
5 – Fast Flash
6 – Quad & Single Flash
7 – Slow Rotation
8 – Normal Rotation
9 – Fast Rotation
10 – Cycle Scan
11 – Steady On (Constant)

WIRING REQUIREMENTS:
• Disconnect battery BEFORE wiring up this lighting product
• Connect RED wire to to POSITIVE (+) vi a a suitable switch
• Install a fuse to the positive (+) wire : 12V 8A / 24V 5A
• Connect BLACK wire to negative(-)
• Momentarily apply WHITE wire to positive (+) to change the flash pattern;
– Less than 1 second for next pattern
– 1-3 seconds for previous pattern
– 5+ seconds resets pattern to STEADY ON / CONSTANT
• Connect YELLOW wire to synchronise multiple beacons
